What Is Monad Execution Events Gateway?

Real-time execution event streaming for the Monad blockchain — beyond what JSON-RPC can offer.

---

The Problem with JSON-RPC

If you're building on Monad today, chances are you rely on JSON-RPC to read blockchain state. You call eth_getBlockByNumber, eth_getLogs, or eth_getTransactionReceipt, and you get back a snapshot of what happened — after the fact.

This works fine for simple use cases. But it breaks down fast when you need:

• Low-latency event delivery. Polling eth_getLogs every few seconds adds hundreds of milliseconds to seconds of delay. For time-sensitive applications — liquidation bots, bridge relayers, real-time dashboards — that delay is unacceptable.

• Execution-level visibility. JSON-RPC gives you the result of execution: logs, receipts, state diffs. It doesn't show you how execution happened — which internal calls were made, which storage slots were touched, how the EVM stepped through the transaction.

• Finality awareness. Standard RPC treats blocks as either confirmed or not. But Monad's MonadBFT consensus has multiple stages — a block can be proposed, voted on, finalized, and verified. Applications that care about finality (bridges, exchanges) need to know which stage a block has reached.

• Lossless delivery. If your WebSocket connection drops for 10 seconds, how many events did you miss? With standard eth_subscribe, the answer is: you don't know. You have to re-scan blocks to find out.

The Monad Execution Events Gateway solves all four problems.

---

What Is the Gateway?

The Monad Execution Events Gateway is a real-time WebSocket streaming service that delivers execution-level events directly from a Monad full node.

Instead of polling for state changes, you open a WebSocket connection, send a subscription message, and receive a continuous push stream of events as they happen. Every event is tagged with a monotonic sequence number (server_seqno) and the block's current consensus stage.

The Gateway exposes event types that are simply not available through JSON-RPC:

• Block lifecycle events — when a block starts executing, receives a quorum certificate, gets finalized, or is rejected
• Transaction internals — full transaction headers, EVM output (gas used, status), internal call frames
• Contract events (logs) — the same emit events you'd get from eth_getLogs, but streamed in real time
• Synthetic events — like NativeTransfer, which surfaces ETH transfers from internal calls
• Network metrics — transactions per second (TPS), per-block contention analysis, top accessed accounts and storage slots

In total, the Gateway exposes 25+ event types across blocks, transactions, contract logs, and network metrics.

---

Key Capabilities

Flexible Subscriptions

You choose exactly what you want to receive. At its simplest:

{"subscribe": ["BlockStart", "BlockEnd", "TPS"]}

This subscribes you to block boundaries and TPS metrics — nothing else.

For more control, use the advanced format with field-level filters:

{
  "subscribe": {
    "events": ["TxnLog"],
    "filters": [{
      "event_name": "TxnLog",
      "field_filters": [
        {"field": "address", "filter": {"values": ["0x0000000000000000000000000000000000001000"]}},
        {"field": "topics", "filter": {"values": ["0xddf252ad1be2c89b69c2b068fc378daa952ba7f163c4a11628f55a4df523b3ef"]}}
      ]
    }]
  }
}

This subscribes to ERC-20 Transfer events from a specific contract — filtered server-side, so you only receive what you need.

Available filters:

Field	Applies to	Description
address	TxnLog	Emitting contract address
topics	TxnLog	Event signature + indexed params (prefix match)
txn_index	TxnLog	Transaction index range in block
log_index	TxnLog	Log index range within transaction
sender	TxnHeaderStart	Transaction sender address
to	TxnHeaderStart	Transaction recipient address
function_selector	TxnHeaderStart	First 4 bytes of calldata

Finality-Aware Streaming

Every event carries the block's consensus stage. You can gate delivery with min_stage:

{
  "subscribe": {
    "events": ["TxnLog", "BlockFinalized"],
    "min_stage": "Finalized"
  }
}

This ensures you only receive events from blocks that have been irreversibly committed by MonadBFT consensus. No reorgs, no rollbacks.

Four stages are available:

Stage	Meaning	Typical Latency
Proposed	Block executed, not yet voted	~0ms (default)
Voted	Quorum certificate from 2/3+ validators	~400ms
Finalized	Irreversibly committed	~800ms
Verified	State root verified	Terminal

Transaction Correlation

When you subscribe to TxnHeaderStart with correlate: true, matching transactions automatically deliver all their child events — logs, call frames, EVM output, and transaction end — without requiring separate subscriptions:

{
  "subscribe": {
    "events": ["TxnHeaderStart"],
    "filters": [{
      "event_name": "TxnHeaderStart",
      "field_filters": [
        {"field": "sender", "filter": {"values": ["0xYOUR_ADDRESS"]}}
      ]
    }],
    "correlate": true
  }
}

Cursor Resume

Every message from the Gateway carries a server_seqno — a monotonically increasing sequence number. If your connection drops, reconnect with:

wss://gateway.example.com/ws?resume_from=12345

The server replays all buffered messages with server_seqno > 12345, then seamlessly transitions to live streaming. No gaps, no duplicates.

Hello Handshake

On connect, the server sends a Hello message with protocol metadata:

{
  "server_seqno": 0,
  "Hello": {
    "wire_version": 1,
    "server_version": "0.1.0",
    "chain_id": 10143,
    "block_number": 59419670,
    "available_filters": ["txn_index", "log_index", "address", "topics", "sender", "to", "function_selector"],
    "blocked_events": ["AccountAccess", "StorageAccess"],
    "limits": {
      "backfill_events": 100000,
      "buffer_per_client": 4096,
      "slow_off_limit": 10000,
      "heartbeat_interval": 30,
      "heartbeat_timeout": 60,
      "max_subscribes": 5
    }
  }
}

This tells you everything you need: which chain you're connected to, what filters are available, which events are blocked, and the server's operational limits.

---

Who Is This For?

Analytics & Monitoring Platforms

Stream block and transaction events to build real-time dashboards — TPS charts, block timing, gas usage, contention heatmaps. The TPS, ContentionData, and Lifecycle subscriptions provide pre-computed metrics without any client-side aggregation.

Bridge & Relayer Infrastructure

Subscribe with min_stage: "Finalized" to guarantee that cross-chain messages are only relayed for irreversibly committed blocks. The Lifecycle subscription lets you track exactly when each block transitions through consensus stages.

Indexers & Data Pipelines

Replace eth_getLogs polling with a push-based stream. Field filters ensure you only receive events for the contracts and topics you care about. Cursor resume guarantees lossless delivery across reconnections.

Wallets & Exchanges

Track transaction finality in real time. Know exactly when a deposit goes from "proposed" to "finalized" to "verified" — and surface that information to users.

Protocol Developers

Debug smart contracts with full execution visibility: internal call frames, storage access patterns, and per-transaction gas breakdown. The ContentionData metric reveals which storage slots cause parallel execution bottlenecks.

---

Quick Start

Using wscat

Connect and subscribe to block events:

# Install wscat
npm install -g wscat

# Connect
wscat -c wss://gateway.example.com/ws

# Send subscription
> {"subscribe": ["BlockStart", "BlockEnd", "TPS"]}

You'll immediately start receiving events:

{"server_seqno": 1, "Events": [{"event_name": "BlockStart", "block_number": 59419671, "block_id": "0x...", "commit_stage": "Proposed"}]}
{"server_seqno": 2, "TPS": 1234}
{"server_seqno": 3, "Events": [{"event_name": "BlockEnd", "block_number": 59419671, "block_id": "0x...", "commit_stage": "Proposed"}]}

Using the TypeScript SDK

import { MonadEventsClient } from 'monad-execution-events';

const client = new MonadEventsClient({
  url: 'wss://gateway.example.com/ws',
});

client.subscribe({
  events: ['TxnLog'],
  filters: [{
    event_name: 'TxnLog',
    field_filters: [
      { field: 'address', filter: { values: ['0x0000000000000000000000000000000000001000'] } }
    ]
  }]
});

client.on('event', (event) => {
  console.log(`${event.event_name} in block ${event.block_number}`);
});

The SDK handles reconnection, cursor resume, and heartbeat detection automatically.

Using the Python SDK

from monad_execution_events import MonadEventsClient

async with MonadEventsClient("wss://gateway.example.com/ws") as client:
    await client.subscribe(events=["BlockStart", "BlockEnd", "TPS"])

    async for event in client:
        print(f"{event['event_name']} — block {event.get('block_number', 'N/A')}")

---

What's Next?

• Finality-Aware Event Streaming: How min_stage Works — Deep dive into consensus stages and how to build finality-aware applications.
• Real-Time Staking Analytics on Monad — Practical guide to tracking Delegate, Undelegate, and validator rewards using the Gateway.

---

The Monad Execution Events Gateway is open source. Check the documentation for the full API reference, or explore the TypeScript and Python SDKs to get started.
